Tripp Lite Surge Protector 14-Outlet Rackmount 15ft Cord 3000 Joules 1URM – Receptacles: 14 x NEMA 5-15R – 3000J W TVSS 3000J 1URM 15FT CORD

VPN: DRS-1215 UPC: 37332100245 SKU: 496655

$156.24

14 OUTLET RACKMOUNT PDU W TVSS 3000J 1URM 15FT CORD

SKU: abd2916b11ff Categories: , ,

Share:

Technical Information
Protection TypeSurge
Receptacles14 x NEMA 5-15R
14 x NEMA 5-15R
Plug/Connector TypeNEMA 5-15P
General Information
Product TypeSurge Suppressor/Protector
Manufacturer Part NumberDRS-1215
Manufacturer Website Addresshttp://www.tripplite.com
ManufacturerTripp Lite by Eaton
Product NameDRS-1215 14 Outlets 120V Surge Suppressor
Brand NameTripp Lite
Physical Characteristics
Shipping Weight (Approximate)5.50 lb
Weight (Approximate)4.60 lb
Form FactorRack-mountable
Height1.8"
Width17.5"
Depth4"
Shipping Height9.30"
Shipping Width2.50"
Shipping Depth20.40"
Power Cord/Cable Length15 ft
Product ColorBlack
Product MaterialMetal
Miscellaneous
Additional Information
    • Snap-in switch guard prevents accidental turn off
Package Contents
  • DRS-1215 14 Outlets 120V Surge Suppressor
  • Warranty information
  • Instruction manual
Compatibility
    • Ideal for protection of sensitive electronic equipment in 19 inch rackmount, wallmount and under-counter applications, such as internetworking equipment, PC systems, telecommunications, audio/video, security and sound reinforcement
Certifications & Standards
    • UL1449 (Let through rating 330V)
    • cUL
    • IEEE 587 category A and B specifications
Country of OriginChina
Environmentally FriendlyYes
Environmental CertificationRoHS
Power Description
Circuit BreakerYes
Input Voltage120 V AC
120 V AC
Power Handling1800 VA
Output Voltage120 V AC
120 V AC
Surge Energy Rating3000 J
Maximum Line Current15 A

Tripp Lite Surge Protector 14-Outlet Rackmount 15ft Cord 3000 Joules 1URM – Receptacles: 14 x NEMA 5-15R – 3000J W TVSS 3000J 1URM 15FT CORD
Tripp Lite’s DRS-1215 offers surge and noise suppression in a versatile all-metal multi-mount cabinet. Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses only 1 rack space (1U) when installed in any 19 inch EIA standard rack. Includes 14 outlets (6 front/8 rear), 15-ft. (4.57 m) AC power cord and guarded power switch to reduce the risk of accidental shutoff. Diagnostic LED indicates surge protection status. PLUG/OUTLETS: Input: NEMA 5-15P/Output: 14 NEMA5-15R (6 front & 8 rear) ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA 5-15R wall receptacle) SUPPRESSION: AC: 140V RMS Clamping/3000 joules FORMAT: Supports 19 in. rackmount (uses 1 rack space/1U), wallmount, under-counter and more Features Versatile all-metal cabinet with detachable mounting flanges allows rackmount, wallmount, undercounter and other creative mounting options Uses one rack space (1U) in standard 19 inch rack (“zero U” mounting possible in many racks) 3000 joules AC surge suppression with EMI/RFI filtering 14 NEMA 5-15R output receptacles (6 front/8 rear) 15-ft. (4.57 m) AC cord with NEMA 5-15P straight-in plug connection Diagnostic LED confirms suppressor operation Lighted power switch confirms power on/off status Snap-in switch guard prevents accidental turn off 15 amp capacity with circuit breaker 120V AC, 50/60Hz electrical compatibility

Tripp%20Lite DRS-1215

Features

14 outlets / 15-ft. cord

3000 joule rating

Adjustable rackmount hardware
